Coherent
Lightwave Technology
for
Methane Gas Imaging
Provide direct measurement of methane emissions, reported by detailed source.
Technology Specifications
| Range | 7-30 meters (23-100 feet) |
| Field of View | 80° horizontal, 60° vertical |
| Maximum Coverage | 43 x 20 meters (140 x 65 feet) |
| Resolution | 1cm over the entire FoV |
| Data Collection Rate | 1-10000 points per second |
| Operating Temperature | -40 to 85°C (-40 to 185°F) |
| Ingress Protection | IP67 |
| Max. Sensitivity | 50ppm-m |
| Min. Detectable Leak | 17g/h |
Coherent Lightwave Technology for Methane Gas Imaging
GeoTeknica is the first to harness the power of Coherent Lightwave Technology (CLT) for spectroscopic methane gas imaging. By exploiting the wave nature of light (frequency, phase, interference, coherence) this technology can dramatically increase sensitivity and frequency selectivity compared to conventional approaches.
Although pioneered in the 1980s, CLT has only recently risen to dominate optical communications systems worldwide with the use of real-time DSP. In anticipation of a similar transformation in gas monitoring, GeoTeknica has developed proprietary DSP algorithms specifically for coherent gas detection using low-cost fiber-optic components produced at scale for telecom systems. The result is a compact and inexpensive scanning laser spectrometer capable of unprecedented sensitivity, speed, and versatility.
(100 feet)
the entire FoV
Sensitivity
Detectable Leak
Search → Locate → Quantify
End-to-End Methane Intelligence
Continuously monitor methane across facilities and infrastructure, perform high-confidence periodic inspections, track tank-level emissions, and detect occluded or hard-to-see leaks with precise location and accurate, real-time measurement.
Coherent methane imaging, dramatically higher sensitivity
GeoTeknica is the first to apply Coherent Lightwave Technology (CLT) to spectroscopic methane gas imaging, leveraging frequency, phase, interference, and coherence for superior selectivity.
Telecom-proven tech, now adapted for gas monitoring
Originally pioneered in the 1980s, CLT now dominates optical communications thanks to real-time DSP—setting the stage for a similar leap in emissions monitoring.
Low-cost fiber optics + proprietary DSP = breakthrough instrument
Purpose-built coherent-gas DSP algorithms enable a compact, inexpensive scanning laser spectrometer with unprecedented sensitivity, speed, and versatility.
